ONU


Product Impression:

          QQ图片20170107133147.png     QQ图片20170106141017.png



Package

Part   No.

Description

EPON ONU

SP-101HC

EPON ONU 1*FE Port, plastic casing, external Power supply

SP-111HC

EPON ONU 1*GE Por,t plastic casing, external Power supply

SP-111HZ

EPON ONU 1*GE Port, plastic casing, external Power supply

SP-104HC

EPON ONU 4*FE Port, plastic casing, external Power supply

SP-112H

EPON ONU 1*FE Port+1*GE Port, plastic casing, external Power supply

SP-104HW

EPON ONU 4*FE Port + built-in Wi-Fi, plastic casing, external Power supply

SP-114GB

MDU EPON ONU 4*GE Port, metal casing, external Power supply

SP-108B-N1

MDU EPON ONU 8*FE Port, metal casing, 220V Power supply, 8*FE interface PoE(PD)

SP-304HC

EPON ONU 4*FE Port+1*CATV plastic casing, external Power supply

SP-304HW

EPON ONU 4*FE Port+1*CATV+WIFI plastic casing, external Power supply

SP-212H

EPON ONU 1*FE Port+1*GE Port +1*POTS Port plastic casing, external Power supply

SP-214HWI

EPON ONU;4*FE Ports +1*POTS Ports+WIFI, plastic casing, external Power supply

SP404-HI

EPON ONU 4*FE Port+1*POTS Port +1 CATV Single Fiber plastic casing, external Power supply

GPON ONU

SP-511HZ

GPON ONT 1*GE Ethernet interface, 1 GPON interface, plastic casing, external power supply adapter

SP-504GH

GPON ONT 4*GE Ethernet interface, 1 GPON interface, plastic casing, external power supply adapter

SP-612H

GPON ONU 1*GE Port+1*FE+1*POTS Port  plastic casing, external Power supply

SP-614HW

GPON HGU ONU ;4*FE Port +2*POTS+WIFI, plastic casing, external Power supply

SP-614GW

GPON HGU ONU ;4*GE Port +2*POTS+WIFI, plastic casing, external Power supply

SP-704H

GPON ONU;4*FE+1*CATV, plastic casing, external Power supply

SP-804HI

GPON ONU;4*FE+1*POTS+1*CATV, plastic casing, external Power supply

SP-804GWI

GPON ONU;4*GE+1*POTS+1*CATV+WIFI, plastic casing, external Power supply




  1. Manufacturer: SOPTO

  2. Latest Price: Contact online customer service NOW!

  3. Working Wavelength: 1550+/-10nm

  4. Optical Reflection Loss: >45dB

  5. RF frequency range: 54MHz~870MHz

  6. Typical RF output level: 90dBuv

  7. CSO: >58dBc

  8. Output reflection loss: >14dB

  9. Output impedance: 75Ω

  10. Maximum Distance: 20km

  11. Maximum splitting Ratio: 1:64 (10km)

  12. Browse the Evaluation: Click here to browse



Performance Features

  1. 4*10/100M Ethernet ports ,2 POT S ports ,1 CATV RF port,1 PON port

  2. External Power Supply

  3. Comply with IEEE802.3ah(EPON),China Telecom EPON technology standard V2.1

  4. Support IEEE802.3AH OAM function

  5. Maximum distance:20km;Maximum splitting Ratio:1:64(10km)

  6. Support various service ,such as  Data ,Voip and IPTV

  7. Support Dynamic Bandwidth Allocation technology

  8. Voip module is adopted Infineon solo chip with high density SOC

  9. Supports three kinds of VoIP protocol, H248/MGCP/SIP

  10. Supports three types of compression calculation method ITU-T

  11. G711 (64Kbps) G723.1 (5.3Kbps/6.3Kbps), G729 (8Kbps);

  12. A/u configuration available

  13. Supports echo cancellation TTU-T G168-2002 with the longest echo cancellation 64ms.

  14. Supports three types of fax, such as transparent transmission under high/low speed mode, T30, T38

  15. Supports Modem (56Kbps) dialing access

  16. Supports DTMF detection and generation



Note: Part in order to prevail in kind. Please contact customer service before buying.



Quality Certification:

  1. Good Anti-electromagnetic interference (EMI)

  2. Good Electromagnetic compatibility (EMC) which is in accordance with FCC Part15.

  3. Meets ISO9001, TUV, CE, FCC, CAS, UL and RoHS certificates



Factory:

  1. Advanced dust-free workshop

  2. Experienced technicians

  3. Mature production technology

  4. Standard production process



Information you want to know more:

  1. Reachable Continents: Asia, Europe, Oceania, Africa, the Americas

  2. Arrival Date: 5 to 7 days

  3. Selectable Logistics: FedEx, DHL, TNT, UPS or EMS

  4. Payment Methods: L/C, T/T, Western Union, HSBC, Paypal as well as Cash Payment

  5. Warranty: 1-3 years

  6. Discounts, Promotions and Gifts: Please just contact our online customer services or pay attention to our website.

 pay=

Related Read:

  1. Payment methods

  2. Delivery guide

  3. Return & Refund

  4. Guarantee

  5. FAQ



Please pay attention to our SNS pages:

Facebook      Twitter      Linkedin



SOPTO ONU 404H Description



ONU SPT-ONU-404H (4FE+2POTS+RF) is a FTTH bandwidth access equipment ,widely applied in the“ three into one “ solution (integrated with Ethernet ,VOIP and CATV) .Based on mature and stable GEPON technology, it has powerful functions with high stability ,sound QoS guarantee ,comprehensive management and flexible networking construction, etc .ONU SPT- ONU-404H’s technology standard fully complies with ITU-T,IEEE,YDT and telecommunication technology standard. It could be used with Sopto local equipment SPT-OLT-2000C to construct EPON system .It could provide three service access, meeting the end users’ demands for surfing, telephone and video entertainment.
