SPGT-P4321-SB2DB

Parmeters

• Form Factor : GPON SFP
• Manufacture : Sopto
• Data Rate : 2488M(Tx)/1244M(Rx)
• Place of Origin : Shenzhen, China
• Transmission distance : Class B+
• Fiber Mode : Single Mode Fiber (SMF)
• Wavelength : 1490nm TX /1310nm RX
• Types of Interface : SC
• Types of Laser : DFB-LD
• Operating Temperature : 0~70°C
• Modes of Communications : Simplex
• Power Supply : + 3.3V Single power supply
• Model : CZGT-P4321-SB2DB
• Operating Humidity : 0%~90% RH no condensing
• Extinction Ratio : 9~17dB
• Receiver Sensitivity : <-32dBm
• Saturated Optical Power : -12dBm
• Hot Pluggable Times : >=200
• Warranty : 1-3 Years
• Typesof Multiplexing : WDM BIDI
• Power Consumption : <1.5W

Specifications

Single Fiber Transceiver with single mode SC receptacle
1490nm continuous-mode transmitter with DFB laser
1310nm burst-mode receiver with APD-TIA
Reset burst-mode receiver design
Burst mode signal detect output which is LVTTL compatible
Burst mode received signal strength indication (RSSI) output
20Km Reach 28dB link budget
Complies with ITU-T G984.2 Class B+
Digital diagnostic interface compliant with SFF-8472 Rev 9.4

Testing Standards

Compliant with ISO9001, TUV, CE, FCC, CAS, UL and RoHS certifications

Application

Gigabit Passive Optical Networks (G-PON) – OLT side

Description

The SPGT-P4321-SB2DB transceiver is the high performance module for single fiber by using 1490nm continuous-mode transmitter and 1310nm burst-mode receiver. It is optical line terminal (OLT) for ITU-T G984.2. The optical transceiver is compliant with the Small Form- Factor Pluggable (SFP) Multi-Source Agreement (MSA).
